Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp

China Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp supplier
Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp supplier Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp supplier

Large Image :  Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp

Product Details:

Place of Origin: China
Brand Name: Superolux
Model Number: SP-30W-6060

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiable
Packaging Details: Neutral package
Delivery Time: 10 working days after received your payment
Payment Terms: T/T o
Supply Ability: 10Kpcs per month
Detailed Product Description
Certification: CE,ROHS Wattage: 36w 40W
Application: Indoor Color Temperature: 2700-7000K
Dimension: 1200*600*13mm LED Source: Super Bright SMD 5630
Input Voltage: 85-265VAC Warranty: 3years
High Light:

600x600 led ceiling lights

,

led panel 600x600





Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp





A) Ultra thin design, 13mm in thickness.



B) Superior raw material.



C) Dimmable optional.



D) High quality light source.



E) Leading heat sink design, four light emission instead of backlight emission.



F) Wide range voltage input.



G) NO UV or infra-red radiation, no mercury or lead, eco-friendly, no danger of broken glass.



H) Built-in high efficiency constant current driver, Wide Voltage AC100-240V 50/60Hz input,

worldwide application.



I) Low energy consumption, saves 60% power comparing conventional light



J) 5 years lifespan (LED), 10 times more than traditional lamp.



K) Be equipped with short circuit, open circuit, lighting stroke, power surge, overcurrent,

over-voltage, overheat etc. protection circuit.



L) Built-in high efficiency constant current driver, Wide Voltage AC100-240V 50/60Hz input,

worldwide application.



M) Easy to install, a perfect replacement for traditional fluorescent tube.



N) 5 years lifespan or > 50,000hrs (LED), 10 times more than traditional fluorescent tube.



O) Light diffusion lampshade or transparent lampshade, by customized.





Product Paramaters:



Model

SP-30W-6060

Input Voltage

AC90-264V 50/60Hz

Dimension

L597*W597*T13mm

Lighting Source

96pcs5630

Power Consumption

30w

Color Temperature

WW(2800~3300K)

NW(4000~4500K)

CW(6000~6500K)

Luminosity

≥3200lm

≥3300lm

≥3400lm

CRI(Ra)

>75

Beam Angle

180°

Work Temperature

-25℃~+45℃

Material

Alu+PMMA

GW

5.2kg

NW

4.5kg

Cap ends

/

Lifespan (LED)

≥50,000hrs  (70% Lumen Maintenance)

IP Rating

IP50

Lumen Attenuation

<5% @ 5,000hrs

Packing Dimension

L710*W640*H34mm





Maintenance:



Pls don’t repair or maintain the product under condition user lack of professional person or knowledge for circuit, especially in absence of necessary equipment, avoiding extending the damage or breaking down the important components.



As there is high voltage circuit inside the product, during maintenance pls don’t dissemble

 orhand touch the PCB under power - on condition. There is isolation protection layer on circuit board, pls don’t touch acidic materials when you disassemble the circuit board, like sweat etc. Please use plate washer water to clean the circuit board when there is stain or dust.



Producing steps and aging pictures



Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp



Dimmable LED Panel Light 600X600 180°Recessed Ultraslim LED Panel Lamp

Package informations


A. Netural carton ,Netural inner package

B  Netural inner package , Customized carton with logo

C  Customized inner package / Carton

with sea shipping ,we will provide standard pallet for export





Free samples services



 we can also provide free samples for the products ,but the clients need to pay the freight cost





Payment methods :





For sampes : T/T Western union in advance



for bulk order 30% downpyment , 70% paid before shipping



or with L/C , payment need to be paid against the bill of landing once goods arrive the destination port
