SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput

China SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput supplier
SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput supplier SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput supplier SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput supplier

Large Image :  SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput

Product Details:

Place of Origin: China
Brand Name: Superolux
Certification: T/T
Model Number: SP-PLCE406060

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiable
Packaging Details: Netural package
Delivery Time: 10 working days after received your payment
Payment Terms: T/T
Supply Ability: 10Kpcs per month
Contact Now
Detailed Product Description
Wattage: 36W 45W 48w Application: Indoor
Color Temperature: 2700-7000K Dimension: 600*600*13mm
LED Source: Super Bright SMD 5630 Input Voltage: 85-265VAC
Certification: CE,ROHS Warranty: 3years



SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput

Product advantages

1. super slim designing

2. convenient for installing , can be both installed by hanging and surface mounted

3. high light output effiency

4. low maitance .

5. fast delivery , 2 weeks after order confirmation



Model

SP-PC6060

Input Voltage

AC90-264V 50/60Hz

Dimension

L597*W597*T13mm

Lighting Source

96pcs5630

Power Consumption

36W

Color Temperature

WW(2800~3300K)

NW(4000~4500K)

CW(6000~6500K)

Luminosity

≥3200lm

≥3300lm

≥3400lm

CRI(Ra)

>75

Beam Angle

180°

Work Temperature

-25℃~+45℃

Material

Alu+PMMA

GW

5.2kg

NW

4.5kg

Cap ends

/

Lifespan (LED)

≥50,000hrs  (70% Lumen Maintenance)

IP Rating

IP50

Lumen Attenuation

<5% @ 5,000hrs

Packing Dimension

L710*W640*H34mm

.
Maintenance:

A. Pls don’t repair or maintain the product under condition user lack of professional person or knowledge for circuit, especially in absence of necessary equipment, avoiding extending the damage or breaking down the important components.



B As there is high voltage circuit inside the product, during maintenance pls don’t dissemble orhand touch the PCB under power - on condition. There is isolation protection layer on circuit board, pls don’t touch acidic materials when you disassemble the circuit board, like sweat etc. Please use plate washer water to clean the circuit board when there is stain or dust.

SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput


Product Size :SMD 5630 Ultra Thin LED Flat Panel Lights For Warehouse Lighting High Lumen Ouput



Package informations


A. Netural carton ,Netural inner package

B  Netural inner package , Customized carton with logo

C  Customized inner package / Carton

with sea shipping ,we will provide standard pallet for export



 Shipping Method:

1. For sample ,TNT .UPS ,DHL ,Fedex , usually take 3-5 days

2. by air . by sea for the massive volume production



Contact US :





info@superolux.com





Mobile:18292019692





whatsapp:13670232205





More about us , please check on : www.ledbulkheadlight.com
