Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz

China Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz supplier
Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz supplier Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz supplier Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz supplier Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz supplier

Large Image :  Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz

Product Details:

Place of Origin: China
Brand Name: Superolux
Certification: T/T
Model Number: SP-PLCE406060

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiable
Packaging Details: Netural package
Delivery Time: 10 working days after received your payment
Payment Terms: T/T o
Supply Ability: 10Kpcs per month
Contact Now
Detailed Product Description
Wattage: 18W 25W 36W 40W Application: Indoor
Color Temperature: 2700-7000K Dimension: 600*600*13mm
LED Source: Super Bright SMD 5630 Input Voltage: 85-265VAC
Certification: CE,ROHS Warranty: 3years





Ultra Slim IP20 LED Panel Light With High Bright 30w 24050 lm 50 / 60 Hz





Model

SP-PLCE306030

Input Voltage

AC90-264V 50/60Hz

Dimension

L597*W297*T11mm

Lighting Source

96pcs 5630

Power Consumption

30W

Color Temperature

WW(2800~3300K)

NW(4000~4500K)

CW(6000~6500K)

Luminosity

≥2450lm

≥2550lm

≥2580lm

CRI(Ra)

>75

Beam Angle

180°

Work Temperature

-25℃~+45℃

Material

Alu+PMMA

GW

2.6kg

NW

2.4kg

Cap ends

/

Lifespan (LED)

≥50,000hrs  (70% Lumen Maintenance)

IP Rating

IP50

Lumen Attenuation

<5% @ 5,000hrs

Packing Dimension

L670*W330*H34mm



Product advantages



1. super slim designing



2. convenient for installing , can be both installed by hanging and surface mounted



3. high light output effiency



4. low maitance .



5. fast delivery , 2 weeks after order confirmation

.



Item

Name

Qty

Unit

Remark

1

600*600 LED Panel Light

1

pc



This packing list for panel light only.

2

User Manual

1

pc

3

Driver

1

pc





Maintenance:



  • Pls don’t repair or maintain the product under condition user lack of professional person or knowledge for circuit, especially in absence of necessary equipment, avoiding extending the damage or breaking down the important components.
  • As there is high voltage circuit inside the product, during maintenance pls don’t dissemble orhand touch the PCB under power - on condition. There is isolation protection layer on circuit board, pls don’t touch acidic materials when you disassemble the circuit board, like sweat etc. Please use plate washer water to clean the circuit board when there is stain or dust.



Producing steps and aging pictures



Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz



Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz



Ultra Slim IP20 LED Panel Light With High Bright 30w 2450 lm 50 / 60Hz
