Product Details:
Payment & Shipping Terms:
|
| Certification: | CE,ROHS, | Wattage: | 20W 30W |
|---|---|---|---|
| Application: | Outdoor | Color Temperature: | 4500K 3000K 6000K |
| Dimension: | 300*300*90mm | LED Source: | Cree |
| Input Voltage: | 85-265VAC 12V 48V 24 V DC | Warranty: | 3years |
| High Light: | led wall pack light,outside wall mounted lights |
||
Grey Black External LED Wall Lights 120 Degree LED Ceiling Light Natural White
Product Feature :
1. Comparing with traditional lamps , more energy saving
2 easy to be installed
3. impact resistance , dust proof , moisture proof
Model Avilable :
| Model Number | Power | IP rate | lumen |
| SP-MLRG270-A10 | 10W | IP65 | 800lumen |
| SP-MLRG270A | 20W | IP65 | 1600umen |
| SP-MLVG280-A10 | 10W | IP65 | 800lumen |
| SP-MLRG300-A | 20W | IP65 | 1600lumen |
| SP-MLRG300-A30 | 30W | IP65 | 2400lumen |
| SP-MLCG300A | 20W | IP65 | 1600 Lumen |
Physical informations about the products :
| Material | Die cast alumium body /PC |
| Input Voltage | 90-305VAC 12/24/48VDC |
| Color Temperature | 3000K |
| Finishing Colour | White Grey Black |
| Beam Angle | 120degree |
| Dimension | 300x300x85mm |
| Warranty | 3 years warranty |
Square LED wall mount ceiling light die cast alumium body
1. Main Technical Parameter:
2. Rated Output Power:20W
3. Rated Input Voltage:85-265 Vac；
4. Rated Input Frequency Range:47～63Hz；
5. Power Factor:≥0.93；
6. Ra>75
7. Material: Pure Aluminum
8. Lamp Size:300*300*90mmmm
9. Rated Initial Luminous Flux: 1600 lm；
10. Rated Color Temperature:3000-6000K
11. LED chip: Epistar
12. Gross weight: 6 kg per pcs
2) Product advantages
1. suitable for indoor applications with IP65 rating
2. IK 10 ,impact-resistance
3. high brightness of light resource
4. avliable for different finishing housing
5. fast delivery , 2 weeks after order confirmation
Applications :
1. Kitchen ,spa ,bathroom ,toliet ,swimming pool
2. villa ,hotel .garden ,lobby
3. meeting room ,office ,factory
Mount methods :
Surface mount /Wall mount
Take 4pcs 5*40mm screw to fix the lamp to the wall, take 4pcs 5*16mm screw
to fix the lamp base and lamp cover.Installation methods : with the tapping
screws installed two holes of base to specified location
4) Producing steps and factory pictures
MOQ :1 pcs
Delivery time :
samples : 3-5 days
massive order : 2-3 weeks
warranty : 3-5 years , depends on the price that the customer prefer
Replacement policy
during the 3 years of warranty period , we offer free replacement of components , when the
products are not used on wrong voltage , and not destroyed by humen being efforts .
Quality Control steps :
1. from the raw materials , we have strict process of test the raw materials
2. On / Off test after assembing
