Product Details:
Payment & Shipping Terms:
|
| Material: | Die Cast Aluminum Housing | IP Rate: | IP 65 |
|---|---|---|---|
| Voltage: | 85-265VAC | Shape: | Oval |
| Size: | 280*180*80mm | Beam Angle: | 120 Degree |
| LED Brand: | SMD 2835 | ||
| High Light: | outdoor ceiling mount led lights,surface mounted led ceiling light |
||
outdoor bulkhead wall light square shape 20W surface mounted led ceiling light high power moisture proof
| Input voltage | AC85V-265V | ||
| Output voltage | 36-43V | ||
| Power factor | ＞0.9 | ||
| Led Q’TY | 120PCS SMD2835 | ||
| Total power of the led | 20W | ||
| Material | Die cast Aluminum housing | ||
| Housing material | PC | ||
| LED light effect | 80LM/W | ||
| Brand of led chip | Epistar | ||
| Light efficiency | Above 80%~90% | ||
| Evenness degree | ＞0.6 | ||
| Related color temperature | 3000K-6500K | ||
| Color rendering | Ra＞80 | ||
| LED chip Junction Temp | ≤85℃ | ||
| Operation temperature | -40℃~+55℃ | ||
| Storage temperature | -25℃~+65℃ | ||
| Grade of protection | IP65 | ||
| Beam angle | 120-140degree | ||
| Connecting wire for the driver | Brown | “L” live line | |
| Blue | “N” neutral line | ||
| Yellow or Yellow-green | “G” earth line | ||
| Dimensions | 300x300x87mm | ||
| NW. / GW. | 1.95KG/2.1KG | ||
| Packing size | 51x34x35cm(5pcs) | ||
| Housing color | White/ Black/ Grey | ||
| Certificates | CE ROHS IK10 | ||
| Warranty | 3years | ||
Parameters :
1. Super bright SMD2835 LED as lighting sources, high efficiency, energy-saving, eco-friendly
2. Side-emitting design to form a surface emitting effect
3. Built-in motion sensor, more intelligently, conveniently and energy-saving
4. Die cast aluminum housing offering high impact capability and strength. PC as cover offering excellent light
transmission
5. Compact structure boosting strong shock resistance, high corrosion resistance, IP65, waterproof, dustproof
and rust-proof
6. Built-in, wide voltage input constant current driver to enable installation around the world
7. Convenient installation methods allowing for application even in dusty and moist locations both indoor and
outdoor
8. More than 50,000 Hours’ lifetime, one-time investment, long-time payback
9. Wide range of color temperature available: 3000K-6500K, and color rendering index can be over 80
10. The beam angle is 180°
Attentions ;
Let the battery charge up for at least 12-16 hours.Then normal operation of this unit should take effect . To check,
press the " TEST " button. The LED lamps on the unit should turn ON. During an electrical power failure, the led
lamps will automatically come on for a minimum of 90 minutes.
