Product Details:
Payment & Shipping Terms:
|
| Product Name: | LED Shoe Box Light /Led Street Light | Power: | 200W |
|---|---|---|---|
| Voltage: | 90-277VAC | CCT: | 3000K /4000K /6000K |
| Beam Angle: | 70*140° | ||
| High Light: | shoe box led light,led area light |
||
Description :led shoe box street light is DLC listed and IP65 Rated , which means it is suitable to work in difficult
weather conditons , it can be widely used for street lighting , parking lot and driverways , outdoor area lighting ,
warehouse and parks .the lumiaries is designed with 3030 chip provides high light efficiency 140lm/Watt ,
can ideally replace Metal halide and HID lamps
200W LED shoebox street light parameters :
| Model | SP-HS200W-A | ||
| Input Voltage | AC85-265VAC 50/60Hz | ||
| Dimension | 336*332*71mm | ||
| Lighting Source | 3528SMD | ||
| Power Consumption | 200W | ||
| Color Temperature | WW(2800~3000K) | NW(4000~4500K) | CW(6000~6500K) |
| Luminosity | ≥20000lm | ≥21000 | >22000 |
| CRI(Ra) | >80 | ||
| Beam Angle | 40*70 | ||
| Work Temperature | -25℃～+45℃ | ||
| Material | Die Cast Aluminium +PC | ||
| GW | 9 | ||
| NW | 8KG | ||
| Power Factor | >0/9 | ||
| Lifespan (LED) | ≥50,000hrs (950% Lumen Maintenance) | ||
| IP Rating | IP65 | ||
| Lumen Attenuation | <5% @ 5,000hrs | ||
| LED Brand | |||
Item No.: SB1200
Product Model: SP-HS200w
Power (W): 200 Watts
Size(mm): 336.4*322.2*71mm
The hole of lamp-post: Φ62mm
Input Voltage(V): AC90-305V 50/60Hz
Color(CCT): 2000K/3000K/4000K/5000K/6000K
Luminous Flux: 130lm/W
LED Quantity: 256 Pcs
Led Type:
Beam Angle: 70*140°
IP Grade: IP65
Power Supply Certificates: CE RoHS SAA CB UL CUL FCC
Operating Temperature: -40-60℃
Anti-lightning: 6KV
CRI: >80
PF: 0.95
Lifespan: 50,000hours
Warranty: 5 years
Product Features :
1) ETL, CETL and DLC 4.0 premium approval, CE and RoHS approval.
2) High brightness SMD 3030 LED chip, LM80 report available.
3) High Luminous Efficiency, up to 130lm/W.
4) Super reliable Mean Well LED Driver or UL approval MOSO led driver to realize long-term reliable and stable
working without failure and maintenance. 5) Unique patented Aluminium die cast design ensures superior heat
management, electrostatic & spray processing, anti ageing, corrosion resistant. 6) Special structure design for
washing off the birds droppings.
7) Beam angle: 70*140°. Reasonable light distribution to ensure an ideal uniformity of brightness on the road
surface, keep the LED lighting efficiency on a high level, no glare.
8) Color temperature 3000k, 4000k, 5000k and 6000k are all available, or we could customize the CCT as per
customer's demand
. 9) Superior color rendition compared to conventional luminaire, CRI>80.
10) Global Voltage Input 90-305VAC, 50/60Hz.
11) IP Grade: IP65, can be used for outdoor harsh environment.
12) Low energy consumption, 75-300W led shoebox light can be direct replacement for up to 250-1000W
HID/HPS/MH etc. 13) Photocell sensor is optional for all the shoebox lights, more energy saving and easy
maintenance.
14) Four types of installation kits are optional. Lamp can be mounted on round and square poles, walls, brackets
according to your request.
15) Resistant to shock and vibration.
16) Start without delay and flicker free. Instant ON/OFF operation.
17) Long operation life time, above 50,000hours. Low maintenance costs.
18) 5 Years Warranty.
