| Material: | Die Cast Aluminum Housing | IP Rate: | IP 65 |
|---|---|---|---|
| Voltage: | 90-277VAC | IK Rate: | IK 10 |
| Luminous Flux: | 1600lumen | Beam Angle: | 360 Degree Beam Angle |
| High Light: | led bulkhead wall light,square bulkhead light |
||
Superolux lighting produces a comprehensive series of led bulkhead light with wide range power , various shape
,different colors .mulitple functions , the classical round shape is with size 300*300*900 mm , with a heat
disspiate die-cast Aluminum housing , the round shape led bulkhead light provides 5 Years warranty with
1600lumen for 20W .
| Model | SP-MLGS20W | ||
| Input Voltage | AC100-277VAC 50/60Hz | ||
| Dimension | 300*300*90mm | ||
| Lighting Source | Epistar/Cree/Samsung | ||
| Power Consumption | 20W | ||
| Color Temperature | WW(2800~3000K) | NW(4000~4500K) | CW(6000~6500K) |
| Luminosity | ≥1500 | ≥1550lm | >1600lm |
| CRI(Ra) | >80 | ||
| Material | Die Cast Aluminium housing | ||
| Work Temperature | -25℃～+45℃ | ||
| Cover Material | PC | ||
| GW | 1.2KG | ||
| NW | 1.0KG | ||
| IK rate | IK09 | ||
| Lifespan (LED) | ≥50,000hrs (950% Lumen Maintenance) | ||
| IP Rating | IP65 | ||
| Lumen Attenuation | <5% @ 5,000hrs | ||
| Power Factor | >0.95 |
||
Product drawing for Square moisture proof outdoor led wall lamp
Installation instruction for 20W square led wall lamp moisture proof
