Product Details:
Payment & Shipping Terms:
|
| Power: | 20W | Voltage: | 85-265VAC |
|---|---|---|---|
| CCT: | 3000K/4500K/3000K | IP Rate: | IP65 |
| Luminous Flux: | 1600lm | Size: | 270*270*80mm |
| High Light: | led bulkhead wall light,square bulkhead light |
||
Description : led bulkhead light is a series of production with die cast Aluminium housing ,IP65
rate .IK09 suitable for applications both indoor and outdoor , such for the moisture areas like
spa ,saunacar parking ,garden ,villas .the 20W bulkhead light can be equipped with motion sensor as well as
emergency pack . it's an excellent lighting solution for both commercial ,public and security lighting .
Specification for 20W led bulkhead light
Power:20W
Size: 270*270*80mm
Voltage:90-275VAC
CCT: 3000K/4500K/6000K
IP rate : IP65
IK rate : IK09
Luminous Flux :1600lm
Finishing Colour : White/Grey/Black
LED bulkhead light Paramters :
| Model Number | SP-MLGC-270 |
| Brand | Superolux |
| LED Light Source | SMD Epistar chip |
| Dimesion | 270x270x90mm |
| LED Luminous Efficiency | 80lm/w |
| Lamp Total Power | 30W |
| Power Efficiency | 0.9 |
| Finsihing Colour | Grey /Black /White |
| Color Rendering Index | Ra >80 |
| Color Temperature | warm white: 2800-3200 k |
| natural white: 4000-4500 k | |
| cool white:5500-6500 k | |
| Beam Angle | 120degree |
| Driver | dimmable /Non-dimmable |
| Input Voltage | AC100-240V |
| Frequency Range | 50/60 Hz |
| Power Factor | ≥0.90 |
| Total Harmonic Distortion(THD) | < 20% |
| -40°C--+80°C | |
| Working Tempeature | -40°C--+50°C; 10%-95%RH |
| Lifetime | > 50,000 hours |
| IK rate | IK10 |
| Lamp Body Material | Die cast aliuium |
| IP Rate | IP65 |
Features for LED bulkhead light :
1. Die cast Aluminium housing .
2. LED board light resource , with smd chips , the light is more uniform ,50000hours life span
3. IK09 rate ,suitable for applications both indoor and outdoor , impact resistance .
Functions for LED bulkhead light .
1.motion sensor can be provided
2.emergency versions can be provided
Time ,brightness can be adjusted in dimmable or emergency period
Product drawing for 20W led bulkhead light
Factory tour about the LED bulkhead light
